Photographs of gas storage tank taken with visible and infrared cameras
The picture on the left shows a gas storage tank as it would look to the naked eye. On the right, the picture was taken with a camera that visualises in the infrared range, which allows us to see methane gas being vented from the tank. This procedure is done regularly to keep the tank pressure at a safe level.
Credit: Howarth, Biogeosciences, 2019
